Thermal Oil Heater Capacity 200.000Kcal/h
Thermal Oil Heater Capacity 200.000Kcal/h
| Yours faithfully | |||||||||
| We hereby submit a price quote for the Thermal Oil Heater 200Mcal/h attached as follows: | |||||||||
| A | Thermal Oil Heater 200.000 kcal/h Koplet set unit | ||||||
| Type | : | IDM 200 | |||||
| Model | : | Horizontal | |||||
| Energy out put | : | 200.000 kcal/h | |||||
| Disegind pressure | : | 7 bar | |||||
| Insullation | : | Rock wool # 100 | |||||
| Inlet/ Outlet | : | DN 40 PN 16 | |||||
| Flue gas outlet | : | ᶲ 350 | |||||
| Accessories | |||||||
| B | Base frame UNP.100 | ||||||
| ͢ | Fuel tank 200 liter dan support | ||||||
| Strorage tank 200 liter dan support | |||||||
| Chimney 6 meter | |||||||
| 1 set pemipaan di area thermal oil heater lengkap dengan instrumentasi. | |||||||
| 2 pcs Globe valve DN40 PN16 | |||||||
| 3 pcs globe valve DN40 PN16 | |||||||
| 1 pcs strainer DN 40 | |||||||
| 1 pcs pressure guage 0-16bar | |||||||
| 1 temp gauge 0 -300c | |||||||
| 5 ball valve DN 15 | |||||||
| 3 tubular level glass | |||||||
| 1 level switch expansion tank | |||||||
| C | Circulation Pump | ||||||
| Complete with skid | |||||||
| Brand /KSB Germany | |||||||
| Electrator motor electrim 5.5 kw/3ph/380/2 pole | |||||||
| D | Expantion Tank | ||||||
| Volume | : | 200liter | |||||
| Diemeter | : | 570 | |||||
| Lenggth | : | 1000 | |||||
| Inlet & Outlet | : | DN50 | |||||
| E | Oil Burner | ||||||
| Brand | : | FBR/Riello/Baltur (Mfg Italy | |||||
| Type | : | Press GW /equivalent burner FBR/Baltur made Italy | |||||
| Capacity | : | 100 -300kW | |||||
| Fuel | : | Light Oil | |||||
| Adapun harga set thermal oil heater | |||||||
| A. Thermal Oil Heater 200.000 kcal/h | |||||||
| B. Base frame UNP150 | |||||||
| C. Circulation Pump | |||||||
| D. Expantion Tank | |||||||
| E. Oil Burner | |||||||
| Information | : | ||||||||||
| Delivery | : | Jabotabek stamps | |||||||||
| Payment | : | Down Payment * 50% | |||||||||
| : | 50% before the goods are shipped | ||||||||||
| Vadility | 4 Weeks | ||||||||||
| Status unit | : | indent 4 weeks | |||||||||
| Work | : | 2 weeks after receiving the down payment (for the purchase of an oil pump, burner, and other instrumentation | |||||||||
| Warranty | : | 1 year after installed or 18 months after the goods are sent | |||||||||
| That’s our offer, thank you for your attention and cooperation | |||||||||||
| PT. Indira Mitra Boiler | |||||||||||
| Ratman | |||||||||||
| (WA) 0813 88 666 204 | |||||||||||
