BENTELER ALLOY STEEL BOILER PIPE MADE IN GERMANY MTC CERTIFICATE

Boiler pipe is a pipe that has special specifications and is used as a boiler manufacturing installation where, this pipe has the characteristics of heat resistance and pressure at hot temperatures. There are many specifications for boiler pipes depending on needs. Boiler pipe dimensions vary in terms of pipe wall thickness and pipe length is generally 7 meters. Carbon Boiler Steel Pipe shows light corrosion resistance and fair strength up to 1000F. However, its use above 800F must take into account the susceptibility to graphitization. Graphitization has not been a significant problem in thickness encountered in tube boilers Use of heavy section pipe above 800F, however, is not recommended.
EN 10216 DI N7175 Boiler Tube Pipe Our EN 10216 DI N7175 Boiler Tube
as a pipe provider with the European German Benteler brand for the needs of Boiler Tube, Tube for Heat Exchanger, Oil Cracking Pipe, Steel Tube for Power Plant, Marine Pipe. The definition of pipe standard EN 10216 DIN 17175 is: EN 10216 Euronorm replaces the old DIN 17175 and 1629 standards. This standard is designed for pipes used in pressure applications, such as pipes. This is why the relevant steel grade is marked with a letter for ‘Pressure’. The value following this letter indicates the minimum yield strength. Subsequent letter designations provide additional information. EN 10216 consists of several parts.
The relevant sections for us are as follows: EN 10216 Sec
1: non-alloy pipe with specified properties at room temperature EN 10216 Part
2: non-alloy pipes with certain properties at higher temperatures EN 10216 Part
3: alloy pipes made of fine-grained steel for any temperature EN 10216 Part
4: Non-alloy and alloy steel tubes with specified low temperatures. Benteler pipe is a certified seamless tube pipe, a pipe brand from Germany which is trusted for its strength and material as a special pipe for boiler tubes and piping and other heating machines, from hot and cold temperatures. .
Boiler tube pipe is a pipe that has resistance to pressure and heat. According to its name, Seamless Boiler Tube Pipe is used for boiler components as a hot steam channel. This pipe is widely used by various industries that use boilers, for example the textile industry, in fact almost all industries and factories use boilers as heaters and hot steam producers.
Product Explanation: Benteler brand seamless boiler pipes are usually used for high pressure and hot media above 500 degrees, for example seamless pipes for pressure vessels for steam boiler machines where the boiler tube has a pipe for water media which is burned at high temperature and at room temperature. condemned, and boiler fabrication standards must use special materials such as the Benteler brand pipes that we sell.

Size Material Weight
Ø 31.80 x 3.20 x 12200mm P235GH TC1 27.54 kg
Ø 31.80 x 3.60 x 12200 mm P235GH TC1 30.55 kg
Ø 38.10 x 3.20 x 12200 mmP235GH TC1 33.60 kg
Ø 38.10 x 3.20 x 12300 mm P235GH TC1 33.88 kg
Ø 38.10 x 3.60 x 12200 mmP235GH TC1 37.72 kg
Ø 42.40 x 3.60 x 12300mm P235GH TC1 42.37 kg
Ø 48.30 x 3.20 x 9000mm CrMo4-5 43.16 kg
Ø 50.80 x3.20x12200mm P235GH TC1 46.58 kg
Ø 50.80 x 3.20 x 12300mm P235GH TC1 46.58 kg
Ø 50.80 x 3.60 x 12200mm P235GH TC1 52.63 kg
Ø 50.80 x 3.60 x 12300mm P235GH TC2 51.54 kg
Ø 50.80 x 5.00 x 12300mm P235GH TC1 69.50 kg
Ø 50.80 x 6.30 x 12200 mm P235GH TC1 86.79 kg
Ø 50.80 x 4.00 x 12200 mmCrMo4-5 56.18 kg
Ø 60.30 x 3.20 x1 2200mm P235GH TC1 54.96 kg
Ø 60.30×3.60 x 12300mm P235GH TC1 61.91 kg
Ø 63.50 x 3.20 x 12300mm P235GH TC1 59.03 kg
Ø 63.50 x 3.60 x 12200mm P235GH TC1 64.89 kg
Ø 63.50 x 3.60 x 12300mm P235GH TC1 65.42 kg
Ø 63.50 x 4.00 x 12300 mm P235GH TC1 72.19 kg
Ø 70.00×3.60 x 12300mm P235GH TC1 72.51 kg
Ø 76.10 x 3.20 x 12300 mm P235GH TC1 69.04 kg
Ø 76.10 x 3.60 x 12200mm P235GH TC1 79.21 kg
Ø 76.10 x 4.00 x 12300mm P235GH TC1 88.32 kg
Ø 76.10 x 5.00 x 12300mm P235GH TC1 111.61 kg
Ø 19.05 x 2.77 x 2242 mm A/SA 179 2.98 kg
Ø 38.10 x3.20×12300 P235GH TC1 33.83 kg
Ø 50.80x 3.60 x 12300mm P235GH TC1 52.16 kg
Ø 50.80 x 6.30 x 12300mm P235GH TC1 85.00 kg
Ø 63.80 x 4.00 x 7000mm P235GH TC2 53.95 kg
Ø 51.00 x 6.00 x 12000mm SA-210 GR.C 106.10 kg
Ø 63.50 x 11.00 x 12000mm SA-210 GR.C 191.36 kg
Ø 60.30 x 4.00 x 12000 mm T91 75.56 kg
Ø 60.30 x 6.00 x 12000 mmT91 109.31 kg
Ø 54.00 x 8.50 x 12000mm T91 127.46 kg
Ø 60.30 x 8.50 x 12000mm T91 147.08 kg
Ø 48.30 x 4.00 x 12300 mmP235GH TC1 53.75 kg
Ø 50.80 x 3.20 x 12300 mmP235GH TC1 46.25 kg
Ø 50.80 x 3.60 x 12300mm P235GH TC1 51.53 kg
Ø 50.80 x 4.00 x 12300mm P235GH TC1 56.83 kg
Ø 50.80 x 6.30 x 12300 mm P235GH TC1 85.00 kg
Ø 60.30 x 3.60 x 12300 mm P235GH TC1 61.88 kg
Ø 63.50 x 3.20 x 12300 mm P235GH TC1 58.57 kg
Ø 63.50 x 4.00 x 2300mm P235GH TC1 72.20 kg
Ø 76.20 x 3.20 x 12300mm P235GH TC1 70.72 kg
Ø 76.20 x 3.60 x 12300 mm P235GH

BST .

OD 31,80×3,60×12200 mm. Grade P235GH TC1

OD. 38,10×3,20×12200 mm. Grade Grade P235GH TC1

OD 38,10×3,20×12300 mm Grade P235GH TC1

OD 38,10×3,60×12200mm Grade P235GH TC1

OD 42,40×3,60x12300mm Grade P235GH TC1

OD 50,80×3,60 ×12200 mm Grade P235GH TC1

OD 50,80 × 5,00 x 12300 mm Grade P235GH TC1

OD 50,80 ×6,30 ×12200 mm Grade P235GH TC1

OD 50,80 × 4,00 ×12200 mm Grade 13CrMo4-5

OD 63,50 ×4,00×12300 mm Grade P235GH TC1

BDS

OD 19,05 × 2,77 × 2242 mm Grade A/SA 179

OD 38,10 × 3,20 × 12300mm Grade P235GH TC1

OD 50,80 × 3,60 × 12300 mm Grade P235GH TC1

BST

OD 51,00 × 6,00 × 12000 mm Grade SA-210 GR.C

OD 63,50 × 11,00 × 12000 mm Grade SA-210 GR.C

OD 60,30 × 4,00 ×12000 mm Grade T91

OD 60,30×8,50×12000 mm Grade T91

OD 54,00 ×8,50 ×12000 mm Grade T91

OD 60,30 ×8,50 × 8500 mmGrade T91

OD 60,30 ×6,00 × 12000 mm Grade T91

BDSG

OD 50,80 ×3,60 ×12300 mm Grade P235GH TC1

OD 50,80 × 4,00 × 12300 mm Grade P235GH TC1

OD 63,50 ×4,00×12300 mm Grade P235GH TC1

OD 76,20×6,30×12300 mm Grade P235GH TC1

BDSG

OD 76,10×5,00 ×6150 mm Grade P235GH TC

OD 50,80 ×4,1 0×6000 mm Grade A213-T12

OD 44,50×5,00 ×6000 mm Grade A213-T22

OD 38,10×4,00 ×6000 mm Grade A213-T22

BST

OD 5 7,10×4,57×6000 mm Grade SA213 T22

OD 50,80 × 5,31 ×6000 mm Grade SA210 C

OD 63,50 ×7,20 ×6000 mm Grade SA210 C

OD 63,50 ×7,20 ×6000 mm Grade SA210 A1

BST

OD 31,80×3,20×12300 mm Grade P235GH TC1

OD 50,80 ×5,00×12300 mm Grade P235GH TC1

OD 50,80×6,30×12300mm Grade P235GH TC1

OD 76,20 ×4,00 ×12300 mm Grade P235GH TC1

BST

OD 101,60 ×4,50 ×11800 mm Grade P235GH TC1

OD 38,10 × 2,77 × 4880 mm Grade P235GH TC1

OD 38,10 x277 x 3810 mm Grade P235GH TC1

BARTHEL

OD 168,30 ×16,00 ×8000 mm Grade 16MO3

OD 355,56×30,00x 8500 mm Grade 16MO3

BST

OD 50,80 ×5,90 ×12300 mm Grade A1

OD 50,80 ×11,00 ×7000 mm Grade T22

OD 57,00 ×4,20 ×12300 mm Grade T2

VLDSG

OD 76,20 x 3,20 ×12300 mm Grade P235GH TC1

OD 60,30 × 3,60 × 12300 mm Grade P235GH TC1

OD 76,20 × 3,60 × 12300 mm Grade P235GH TC1

VLDSG

OD 50,80 ×3,20 × 12300 mmGrade P235GH TC1

OD 38,10 ×3,60 × 12300 mm Grade P235GH TC1

OD 60,30 ×3,60 × 12300mmGrade P235GH TC1

OD 63,50 ×4,00 ×12300mm Grade P235GH TC1

OD 63,50×4,00 ×12300 mm Grade P235GH TC1

OD 70,00 ×3 ,60×12300 mm Grade P235GH TC1

OD 76,20 ×4,00×12300 mmGrade P235G H TC1

BST

OD 60,30 ×3,20×12300 mm Grade P235GH TC1

OD 60,30×3,60 ×12300mm Grade P235GH TC1

OD 63,50 × 3,20 ×12300mm Grade P235GH TC1

OD 63,50 × 3,60 ×12300 mm Grade P235GH TC1

OD 70,00 ×3,20 ×12300 mm Grade P235GH TC1

OD 70,00 ×3,60 × 12300 mm Grade P235GH TC1

OD 76,10 ×5,00 ×12300 mm Grade P235GH TC1

OD 76,20×4,00 ×12300 mm Grade P235GH TC1

OD 48,30×4,00 ×12300mm Grade P235GH TC1

OD 50,80×3,20 ×12300 mm Grade P235GH TC1

OD 50,80 ×3,60 ×12300 mm Grade P235GH TC1
